Manual Stacker with Adjustable Forks
Manual Hand Stacker range has a compact design to allow for usage in tight areas. It also features a number of added safety features to protect the operator.
Versatile, compact and heavy duty handling machines, Manual Stackers are designed to make manoeuvring of heavy loads a simple task. The removable solid platform reveals adjustable forks to suit almost every type of load!
Features:
- Heavy duty powder coated steel construction
- Adjustable fork width from 250-550mm (overall measurement)
- Removable steel platform attaches via simple hook bracket
- Hydraulic foot pump for controlled raising and lowering
- Swivel braked rear castors for easy manoeuvring and safety
- Concealed load bearing castors with protective surround
- Perspex safety shield comes standard on all models
- 3 Lift Heights available - 1100mm, 1500mm, 1700mm
- Fork size on all models is 610mmL x 120mmW
| Model | Overall Dimensions (mm) | Platform Size (mm) | Lift Height Range (mm) | Capacity | Unit weight |
|---|---|---|---|---|---|
| 11740246 | 1010L x 580W x 1375H | 650L x 580W | 90 - 1100 | 400kg | 65kg |
| 11740247 | 1010L x 580W x 1770H | 90 - 1500 | 85kg | ||
| 11740248 | 1010L x 580W x 1975H | 90 - 1700 | 115kg |
